Graphite Steel Rolls (GS)

Home / Product / Cast Steel Roll / Graphite Steel Rolls (GS) / Graphite Steel Rolls Grade 190 (GS190) for Blooming mills
  • Graphite Steel Rolls Grade 190 (GS190) for Blooming mills
  • Graphite Steel Rolls Grade 190 (GS190) for Blooming mills
  • Graphite Steel Rolls Grade 190 (GS190) for Blooming mills
  • Graphite Steel Rolls Grade 190 (GS190) for Blooming mills

Graphite Steel Rolls Grade 190 (GS190) for Blooming mills

Graphite Steel Rolls 190 (GS190) used in the blooming mill has good thermal conductivity and can effectively dissipate heat and keep the temperature of the roll stable, which is beneficial to improving the surface quality and dimensional accuracy of the rolled products. Graphite Steel rollers 190 (GS190) are suitable for various roughing mills and can meet the rolling needs of metal billets of different sizes and materials. Compared with some more expensive roll materials, graphite steel rolls have lower manufacturing costs, but their performance can still meet the requirements of the blooming mill and is cost-effective.

Hardness HSD: 50-65
Nickel composition %: 0.6-2.2
Suitable for racks: Chinese steel rolling

Inquiry Us
  • Graphite Steel Rolls Grade 190 (GS190) for Blooming mills
  • Graphite Steel Rolls Grade 190 (GS190) for Blooming mills
  • Graphite Steel Rolls Grade 190 (GS190) for Blooming mills
  • Graphite Steel Rolls Grade 190 (GS190) for Blooming mills
PREV：No previous article
NEXT：Graphite Steel Rolls Grade 160 (GS160) for Roughing Mill

Performance Parameter

Graphite Steel Roll (GS)

 Chemical Composition %
Symbol C Si Mn Cr Ni Mo P S
GS150 1.40-1.60 1.00-1.70 0.60-1.00 0.60-1.00 0.20-1.00 0.20-0.50 ≤0.035 ≤0.030
GS160 1.50-1.70 0.80-1.50 0.60-1.00 0.50-1.50 0.20-1.00 0.20-0.80 ≤0.035 ≤0.030
GS190 1.80-2.00 0.80-1.50 0.60-1.00 0.50-2.00 0.60-2.20 0.20-0.80 ≤0.035 ≤0.030



Prosperities & Application
Symbol Hardness Dimension Application
HSD MM
GS150 40-50 ￠400-1400 Section mills, bar and wire mills; blooming mills; hot strip roughing rolls and edger rolls; and section universal mills.
GS160 45-55
GS190 50-60;55-65
